Commercial Bathroom Mirror, Stainless Steel Channel Frame Mirror with Shelf

$86.10

Availability : In Stock

Product Type : Commercial Mirrors

Vendor : American Specialties

SKU : HDM-ASI-M0625

All Mirrors are subject to additional shipping charges. This is a quote by quote basis. PRODUCT OVERVIEW STAINLESS STEEL CHANNEL FRAME MIRROR WITH SHELF with 18 gauge stainless steel shelf with satin finish and all edges returned and hemmed for maximum rigidity and safety. Shelf is welded to face frame...


All Mirrors are subject to additional shipping charges. This is a quote by quote basis.

PRODUCT OVERVIEW

STAINLESS STEEL CHANNEL FRAME MIRROR WITH SHELF with 18 gauge stainless steel shelf with satin finish and all edges returned and hemmed for maximum rigidity and safety. Shelf is welded to face frame and is 5" (127 mm) wide.

All Mirrors are subject to additional shipping charges. This is a quote by quote basis.

COMPONENTS AND MATERIALS

  • Frame: 18-8, type 304, 20 gauge (.036" <.91mm> thick) stainless steel. Roll-formed one piece construction. Exposed surfaces have a No 4 satin finish. Edges and corners are burr free.
  • Shelf: 18-8, type 304, 18 gauge (.048 in. <1.2mm> thick) stainless steel. Unitized all welded construction. Exposed surfaces have satin finish. Edges and corners are burr free.
  • Glass: Standard glazing is No 1 quality, 1/4" (6.4mm) thick plate/float, silver coated and hermetically sealed with a uniform copper plating, and warranted against silver spoilage for 15 years. Mirrors meet Federal Spec DD-M-411C, ASTM C- 1503, and ASTM C-1036-91.
  • Filler: Expanded polyethylene microcell foam sheet material, abrasion resistant and shock absorbing, water resistant, 1/8 inch (3.2mm) total layer thickness.
    Installation
    Install brackets level and plumb per diagram location using No10 self tapping screws (by others). Hang mirror on brackets and tighten locking screws provided at top & bottom. For ADA compliance, bottom edge of reflecting surface should be no higher than 40"(1016mm) above finished floor.

    SPECIFICATIONS

    Channel Frame Mirror with Shelf shall have frame fabricated of 20 gauge alloy 18-8 stainless steel, type 304 with mitred corners. Shelf shall be 18 gauge, same grade. Mirror glazing shall be (insert glazing option) and shall be warranted for 15 years against silver spoilage. All edges of mirror shall be protected by friction and chafe absorbing fillers. Back of mirror shall be protected by full size shock-absorbing water-resistant filler and full size one piece 20 gauge corrosion pro- tected steel. Top and bottom wall mounting brackets shall be spot welded into an "H" for easy installation. Mirror shall be secured to lower bracket with a Philips Pan Head locking screw. Finish of unit shall be protected from marring by easily removed self-adhesive PVC film.
